TAD-G-SI-1C

TAD-G-SI-1C Silikonkleber thermisch leitfähig

TAD-G-SI-1C is a liquid addition cure corrosion-free highly thermally conductive 1 part silicone adhesive. It cures at elevated temperature over 100°C to a strong but still elastic rubber and exhibits excellent primerless adhesion to most surfaces. The adhesive features good thermal conductivity. It allows for being operated at temperatures up to 260°C and does not corrode copper or its alloys when fully cured. It is characterised by high resistance to water, acids, bases and most organic solvents and is especially suitable for applications where high thermal conductivity, adhesion, fast curing and controlled, precision application are essential.

PROPERTIES
  • Thermal conductivity: 1.38 W/mK
  • High bonding properties
  • Heat addition cure
  • Non corrosive
  • High operating temperatures up to 260°C
  • Extraordinary chemical resistance and longterm stability
AVAILABILITY
  • 1 kg jars
  • 310 ml cartridges
  • Bulk packaging options on request
  • Optional with glass beads
    e.g. 0.2 mm (TAD-G-SI-1CG200)
APPLICATION EXAMPLES
  • LED systems
  • Processor cooling
  • Memory chip assembly
  • CPU board
OVERVIEW
PropertiesUnitTAD-G-SI-1C
MaterialSilicone
ColourGrey
Specific Gravityg/cm³2.06
Linear Shrinkage%2.0
ViscosityPas43
HardnessShore A67
Tensile Strengthpsi3.1
Elongation%70
Curing Time (@ 100°C))min30
Shelf Life (from Date of Manufacturing, unopened, @ < 15°C)Months6
FlammabilityUL 94HB (1.5 mm)
RoHS Conformity2015 / 863 / EUYes
Thermal
Thermal ConductivityW/mK1.38
Coefficient of Thermal Expansion Volumetricx 10-6/K562
Coefficient of Thermal Expansion linearx 10-6/K187
Operating Temperature Range°C- 50 to + 260
Electric
Dielectric StrengthkV/mm22.5
Volume ResistivityOhm - cm7.7 x 1015
Surface ResistivityOhm - cm1.3 x 1015

/
